Turbo Turbocharger for Mistubishi Pajero 4D56 4D56T 2.5L TD04-10T Water + Oil Cooling 49177-01502
Introductions:
A turbocharger, colloquially known as a turbo, is a turbine-driven, forced induction device that increases an internal combustion engine's efficiency and power output by forcing extra compressed air into the combustion chamber.
Features:
* Product Material
1. Turbine housing: Ductile iron QT450-10- temperature resistant up to 700℃
2. Steel turbine wheel: K418 alloy - high oxidation stability and resistance up to 900℃
3. Compressor housing: ZL104 aluminum with lightweight
4. Compressor wheel/blades: Cast aluminium blades – superior air tightness corrosion resistance
* Product Performance
1. OEM-quality and size with little modification
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance
* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS VSR3
2. G3-min-Flow VNT Turbo testing
3. Advanced Actuator Tester/Programmer
Application
For Mitsubishi Pajero, Shogun 2.5L 4D56T
For Hyundai Gallopper 2.5 TDI Engine D4BH (4D56 TCI) 1996-
For Mitsubishi Gallopper TCI Engine D4BH (4D56 TCI) 1996-
For Mitsubishi L200 2,5L TD 4x4 Engine: 4D56 (Turbo) 1996-1998
For Mitsubishi Pajero II 2.5L TD 1993-
*Notice:
The flange of turbine outlet is 5-bolts,not 3-bolts.
Please be sure to check your engine code is 4D56/D4BH before purchasing.
Turbo Part Number & OEM Number
4917702512, 49177-02512, 4917702513, 49177-02513,
4913504020, 49135-04020, 4913504021, 49135-04021,
4917707612, 49177-07612, 282004A200, 28200-4A200,
2820042540, 28200-42540, MD194845, MR355225,
*This turbo is with oil and water-cooling bearing housing that would fit original oil-cooled turbo with OE/PN number below, but need to close water hole:
49177-02500, 4917702500, 49177-02501, 4917702501,
49177-02510, 4917702510, 49177-02511, 4917702511,
MD187208, MD170563, MD187211, MD155984,
Specification
Exhaust Inlet Flange: 3 Bolts
Exhaust Outlet Flange: 5 Bolts
Horsepower: 73KW/ 98HP
Turbo Model: TD04-11G-4 , TD04
Engine: 4D56, D4BH
Cooling Type: Water+Oil Cooling
Bearing Type: Floating Bearing
Thrust Bearings: 270 Degrees
Turbo Type: Individual
Condition: 100% Brand New
Accessories: You will receive the parts exactly as shown in the picture above
Package Size: 27*24*22cm
Package Weight: 5100g
Feature
* Product Material
1. Turbine housing: Ductile iron QT450-10- temperature resistant up to 700℃
2. Steel turbine wheel: K418 alloy - high oxidation stability and resistance up to 900℃
3. Compressor housing: ZL104 aluminum with lightweight
4. Compressor wheel/blades: Cast aluminium blades – superior air tightness & corrosion resistance
* Product
1. OEM-quality and size with little modification
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance
* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS VSR3
2. G3-min-Flow VNT Turbo testing
3. Advanced Actuator Tester/Programmer
Package Includes:
1 x Turbocharger
Code:MGGRP
Authority ID: MXR02FXSY
