K03 Turbo Turbocharger For VW Passat Audi A4 1.8T 1996 -2004 53039880029
Turbo Model:K03
Applications:
1998-99 for Audi A4 1.8T (B5) Engine Code APU; ARK
2002-05 for Audi A4 1.8T (B6) Engine Code BFB
1998- for Audi A6 1.8T (C5) Engine Code APU; ARK
1996-00 for Volkswagen Passat B5 1.8T Engine Code APU; ARK
2000-05 for Audi A4 with AMG; AWM; ATW; AUG Engine
2000-05 for Volkswagen Passat with AMG; AWM; ATW; AUG Engine
Part Number:
53039880029; 5303-988-0029; 5303 988 0029;
53039700029; 5303-970-0029; 5303 970 0029;
53039880025; 5303-988-0025; 5303 988 0025;
53039700025; 5303-970-0025; 5303 970 0025;
058145703J; 058145703JX; 058145703JV;
058145703K; 058145703KX; 058145703KV;
058145703N; 058145703NX ; 058145703NV;
058145703Q; 058145703QX; 058145703QV
Specification:
Compressor :
Wheel Diameter: 50/36 mm
Trim: 51.8
Compressor Inlet: 44.4mm
Compressor Outlet: 50mm
Blades: 6 x 6 blades
Turbine :
Wheel Diameter: 44/40 mm
Trim: 82.6
Blades: 11 blades
Inlet Flange: 3 Bolt Flange
Outlet Flange: 3 Bolt Flange
===================================
Turbo Model: K03
Engine: APU/ARK/BFB/AMG/AWM/ATW/AUG
Fuel: Gasoline
Cooling Type: Water Oil Cooling
Horsepower Rating: up to 150 HP
Bearing Type: Floating Bearing
Thrust bearings: 270 Degrees
Turbo Type: Individual
Universal Fitment: No
Finish: Matte
Condition: Brand New
Accessories: You will get exactly as shown in the picture above
Package Weight: 5700g
Package Size: 26*25*23cm
Feature:
* Turbine housing adopts ductile iron QT450-10; withstand temperatures up to 700℃.
* Steel Turbine Wheel made from the special K418 alloy to achieve high oxidation resistance and stability under high temperatures up to 900℃.
* Cast aluminium blades with good air tightness and corrosion resistance
* OEM-quality and size with little modification
Note:
* Please confirm your original turbo PART NUMBER before Purchasing
* Professional installation is highly recommended
* Before installing the new turbocharger; the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply; foreign bodies in the intake area; crankcase ventilation without function; etc.)!
Notice:
California Prop 65 Warning
Code:MXR02FXSY
