Coilover Suspension Kits for Honda Civic EG/EK/EJ 1996-2000 Adjustable Damper Coil Springs & Struts
Features:
100% , NEVER USED OR INSTALLED
HEIGHT ADJUSTMENT VIA SHOCK BODY, NOT SPRING
24-CLICKS OF DAMPING ADJUSTMENT (COMPRESSION/REBOUND) SIMULTANEOUSLY
FRONT CAMPER PLATES STANDARD ON APPLICABLE KITS
ALUMINUM FRONT AND REAR BOTTOM MOUNTS
ALUMINUM ANODIZED TOP HAT& COLLARS
FULLY ANODIZED RUST RESISTANT SLEEVES.
1 Year LIMITED WARRANTY AGAINST MANUFACTURER DEFECT
ROD DIAMETER: FRONT-22MM / REAR-12.5MM
Fitmemt:
For HONDA CIVIC 1989-1991 ED2 ED3 ED4 ED6 ED7 EC8 EE9 Rear FORK TYPE BRACKET MODEL ONLY
For HONDA CRX 1989-1991 ED8 ED9 EE8 Rear FORK TYPE BRACKET MODEL ONLY
For HONDA CIVIC 1992-1995 EG1 EG2 EG3 EG4 EG5 EG6 EG8 EG9 EJ1 EJ2 EH2 EH3 EH9 Rear FORK TYPE BRACKET MODEL ONLY
For HONDA CIVIC 1995-2000 EK1 EK2 EK3 EK4 EJ6 EJ7 EJ8 EM1 Rear FORK TYPE BRACKET MODEL ONLY
For HONDA DELSOL 1993-1997 EG1 Rear FORK TYPE BRACKET MODEL ONLY
For ACURA INTEGRA 1994-2001 DC2 DC4 Rear FORK TYPE BRACKET MODEL ONLY
Specifications:
- Front and Rear top mount: rubber
- Damping: 24 levels rebound damping adjustable
- Spring rate Front: 8 kg/mm (448 lbs/in)
- Spring rate Rear: 5 kg/mm (280 lbs/in)
- Spring length Front: 180mm
- Spring length Rear: 180mm
- Adjustable height: lowering 1-3inch
- Coilover overall length Front: 365mm-410mm
- Coilover overall length Rear: 435mm-480m
- Rod diameter: Front-22mm / Rear-12.5mm
- Shock type: Twin tube
- Spring Preload: 7-10 mm
- Color: Silver
Package Including:
1 x Set of Coilover Spring Kit (2 Front + 2 Rear)
1 x Pair of wrenches for height adjustment
Note: For some vehicles, you will need sleeves washers that already included in our package.
