4 Pieces Heavy Duty 2500lb 1/2"NPT Double Bellow Air Suspension Bag Air Spring bags
Introduction:
Car air suspension spring bag is one of the most popular suspension kits available; it delivers some of the greatest performance benefits and convenience for all types of vehicles. Air bag suspension kits raise the vehicle high enough to compensate for any extra weight. This helps to keep the vehicle level while towing and hauling and prevents rear sagging; bottoming out; and excessive pressure on your tires.
We provide a full assortment of air suspension spring bags for all your suspension need!
Standard 2500 lb Air Spring Bags Part 1/2"npt Single Port Air Shock Suspension
Fit for:
Universal Air Suspension Bags for Ford F150/F250; for GMC Sierra; for Chevrolet Silverado; for Dodge Ram 1500 2500 3500; etc
Please confirm whether the air spring bag parameters below (especially height; diameter; bolt specifications) are consistent with ours before purchasing.
(Fits for most brand trucks)
Specifications:
Min height: 65mm
Max height: 175mm
Working stroke: 110mm
Loading Cap. at 3.0bar: 2.88KN
Loading Cap. at 7.0bar: 7.25KN
Single air port size: 1/2NPT
Install hole size:3/8-16UNC
Top plate diameter:113mm
Air spring bag body diameter:145mm
Air spring bag capacity: 2500LBS
Condition: 100% Brand New
Quantity: 4 pieces in one set. (for rear / front left or right)
Features:
- Features with heavy duty double convoluted crimped design which allows safe and comfortable load capacity up to 2500 pounds.
- Hold up to 350 PSI.
- Test more than 3 million times.
- 100% Air Tightiness testing.
- Gives the driver more control of ride.
- Built to strict quality control standards.
- Designed for Comfort Suspension.
Notice
- These air suspension bags are aftermarket ones. They will replace the original air spring bags.
- Please double check the picture and drawing carefully before purchasing to ensure you will get the right struts.
Code: MXR02FXSY
